产品特性:
- 1或2个泵模块
- 配有标准的最低液位开关和目视最高液位开关
-“快速更换”泵模块: 泵维护时可以不用断开管路更换元件
- 系统兼容:- 02双线系统 - 26递进系统
- 油箱容量: 10 KG, 30 KG
- 排量: 25cc/min ( 1个泵模块); 50cc/min ( 2个泵模块)
- 工作环境温度: -5°C ~ +50 °C
迷你Sumo泵最适合用于26系列递进系统和02双线系统 . 可适用于稀油和油脂润滑，润滑剂等级可选到NLGI-2.
2个流量25cc/min的泵模块串联安装，压力可高达400bar.
如果一个泵模块不工作，另一个泵模块也可以最大压力供油。不用断开管路，在更换下一个泵模块之前也可以保证泵的正常运转.
维护时 0 停工时间
“快换系统”允许不用断开管路快速更换泵模块。不用断开管路同时也降低了污染.
如需访问技术文档下载专区，请在页面右上角登录或者注册。
| Availability | Part Number | Description | Price | Lot Size | Buy |
|---|---|---|---|---|---|
| 2487000 | MINISUMO GREASE 10Kg-3PH | ||||
| 2487000-001G0 | MINISUMO GREASE 10Kg-3PH | ||||
| 2487001 | MINISUMO-GREASE-30KG--3PH | ||||
| 2487001-001G0 | MINISUMO-GREASE-30KG-3PH | ||||
| 2487010 | MINISUMO GREASE 10Kg-1PH 110V | ||||
| 2487011 | MINISUMO GREASE 10Kg -1PH 230V | ||||
| 2487012 | MINISUMO GREASE 10Kg - 24V | ||||
| 2487013 | MINISUMO GREASE 30Kg -1PH 110V | ||||
| 2487014 | MINISUMO GREASE 30Kg -1PH 230V | ||||
| 2487015 | MINISUMO GREASE 30Kg - 24V | ||||
| 2487050 | MINISUMO OIL 10Kg - 3PH | ||||
| 2487051 | MINISUMO OIL 30Kg - 3PH | ||||
| 2487060 | MINISUMO OIL 10Kg -1PH 110V | ||||
| 2487061 | MINISUMO OIL 10Kg -1PH 230V | ||||
| 2487062 | MINISUMO OIL 10Kg - 24V | ||||
| 2487063 | MINISUMO OIL 30Kg - 1PH 110V | ||||
| 2487064 | MINISUMO OIL 30Kg - 1PH 230V | ||||
| 2487065 | MINISUMO OIL 30Kg - 24V |
| Availability | Part Number | Description | Price | Lot Size | Buy |
|---|---|---|---|---|---|
| 0083480 | ELECTROMAGNETIC-SWITCH | ||||
| 0083481 | ELECTROMAGNETIC-SWITCH | ||||
| 0083482 | ELECTROMAGNETIC-SWITCH | ||||
| 0083483 | ELECTROMAGNETIC-SWITCH | ||||
| 0083490 | 24V ELECTROMAGNETIC-SWITCH KIT | ||||
| 0083491 | 110V AC ELECTROMAGN-SWITCH KIT | ||||
| 0083492 | 230V AC ELECTROMAGN-SWITCH KIT | ||||
| 0083494 | 24V DC ELECTROPNEUM-SWITCH KIT | ||||
| 0083496 | 110V AC ELECTROPNEU-SWITCH KIT | ||||
| 0083550 | DIRECTIONAL VALVE 4/3-KIT | ||||
| 0083950 | ASM.REVERSING VALVE-IDRAULIC | ||||
| 0086450 | REVERSING-VALVE-60÷300bar | ||||
| 0234496 | BYPASS VALVE-80-380BAR-ADJ | ||||
| 0295046 | FIXING PLATE INVERTER | ||||
| 0295066 | HEATER | ||||
| 0295100 | KIT-LEVEL-MAX-30/100KG | ||||
| 0295120 | MIN CAPACITIVE 30 kG LEVEL KIT | ||||
| 0295140 | ULTRASOUND LEVEL | ||||
| 0295150 | 30Kg OIL LEV. FLOAT KIT | ||||
| 0295151 | 10Kg OIL LEV FLOAT KIT | ||||
| 0295170 | MAX CAPACITIVE LEVEL KIT | ||||
| 0295180 | IND.LIVELLO-KIT LASER 30 KG | ||||
| 0297001 | RED. GEAR-1/35-63-B14 | ||||
| 0297007 | FILTER CARTRIDGE | ||||
| 0297033 | BRACKET ASSEMBLY | ||||
| 0297200 | MIN CAPACITIVE 10 kG LEVEL KIT | ||||
| 3130138 | REFILLING PLUG WITH FILTER | ||||
| 3190485 | GASKET-NBR-O-RING-4825 | ||||
| 3301557 | D.C. MOTOR 24V+EMC+COUNTERFLAN | ||||
| 3301558 | MOTOR-63-0.25KW-1PH-4P-110V | ||||
| 3301559 | MOT-63-0.25KW-1PH-4P-230V-50Hz |
C2158PE
C2158PI
C2158PF
C2158PG
C2158PS
C2158PP
C2158PR
C2158PC
