BRAVO 4.0

Manual / LTC (Lubricate Time Control)

Key features:
- Voltage: 12V AC / DC - 24V AC /DC - 110V / 230V 50 / 60 HZ
- Flow rate: 4 cm³ / min (0.24 in³ / min) 0,6 ÷ 4 cm³ / min (0.04 ÷ 0.24 in³ / min) adjustable
- New tank design
- Tank capacity grease versions w/follower plate: 2 – 4 – 8 – 12 lt
(0.53 – 1.05 – 2.11 – 3.17 US gallons)
- Bracket for mounting on wind turbines
- IoT monitoring of lubricant level

The BRAVO 4.0 electric pump is a robust and compact piston pump, designed for progressive grease and oil lubrication of machinery used in various sectors.

This pump was developed to meet multiple spare-related requirements, therefore it can be equipped with tanks of different capacities, as required. The tank is made of plastic (PET), and it has fixing holes that reduce the possibility of lubricant leakage to zero, and other features that make it easy to install.

The pump is available in 2 macro-versions, which can be used with Grease, Oil and Wind Turbine Plate Disk:

- Manual:
it can be managed by PLC and external connectors; as it is not equipped with an internal control unit, it is a cost-effective solution for lubricating your equipment.

- LTC (Lubricate Time Control):
with programmable PCB and DIP Switch; it is equipped with run/error LED signals.

Applications

- Glass or woodworking machinery
- Earthmoving and agriculture machinery
- Mining or construction industry
- Wind turbines
- Chains and gears

Advantages

- It is designed to operate with up to three pumps, for an overall higher flow rate.
- A remote reset button for LTC versions can be supplied as optional.
- The main body of the pump is made from high performance robust plastic and is compact in size designed to withstand tough environments.
